Wave spectral density (calculation)

Sea calculation

The performance of a sailing boat is affected by the presence of surface waves. To understand the boat’s behavior under waves, it is necessary first to model the irregular shape of the water surface or sea state.

The most common method used for describing the sea state is through the “wave spectral density, “also known as “wave energy spectrum, “or simply “spectrum.” For most ship, offshore structures, and boat applications, two main single-modal spectra (for pure wind waves or swell-only cases) are used:

  • Bretschneider spectrum for fully developed seas;
  • JONSWAP spectrum for fetch-limited situations.

Both the Bretschneider and the JONSWAP spectrums can be characterized by two parameters:

  • The significant wave height, H1/3, and
  • The modal period, T0, also known as the peak period.
In general, the Bretschneider spectrum has a greater frequency bandwidth than the JONSWAP spectrum. H1/3 = 4m, To = 10 s.

Calculation template

Wave forecasting

In deep water, the significant wave height, H1/3, and the modal or peak period, T0, of a sea state can be estimated with the Breugem and Holthuijsen wave growth nomogram, where:

  • red lines represent the growth of waves along an increasing fetch and correspond to a constant wind speed;
  • green lines represent the fetch in nautical miles;
  • the vertical lines indicate the duration in hours at which that stage of development will be reached from zero wave height.

For a given wind speed, fetch, and wind duration, the significant wave height, H1/3 (in meters), is obtained from the horizontal black lines, and the modal or peak period, T0 ( in seconds), is obtained from the blue lines in the nomogram.

Breugem and Holthuijsen wave growth nomogram
Breugem and Holthuijsen wave growth nomogram
